The population standard deviation of the pixel values of the first input raw bias is computed. This is the combination of structure, fixed pattern noise, and read out noise. The read out noise and the fixed pattern noise contributions are then quadratically subtracted.
can be found in the plot tutorial.
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
