The METIS infrared instrument for the E-ELT

METIS is one of the Phase 1 instruments for the E-ELT. It will offer imaging and medium-resolution spectroscopy over a wavelength range from 3–19 micrometres, and high-resolution integral field spectroscopy over a wavelength range of 3–5.3 micrometres. METIS is the only E-ELT Phase 1 instrument to work at these longer mid-infrared wavelengths and complements the MICADO camera and HARMONI spectrograph.

This engineering drawing shows a cutaway view of the METIS.

Credit:

ESO/METIS consortium

About the Image

Id:ann15073e
Type:Artwork
Release date:28 September 2015, 15:00
Related announcements:ann15073
Size:4000 x 3000 px

About the Object

Name:METIS (Mid-infrared ELT Imager)
Type:Unspecified : Technology : Observatory : Instrument
Category:ELT
